| Standard Frequency | 32.768HZ | Adjust the frequency difference | ±20ppm/±10ppm |
| Operating temperature | -40°-+85° | Storage temperature | -55°-+125° |
| Static capacitance | 1.2 pF | Dynamic capacitance | 3 pF Max |
| Insulation Resistance | 500MΩ Min | Excitation power | 1.0 μ W Max |
| Load capacitance | 6pF-12.5pF | Conversion temperature | 25±5° |
| Parabola Coefficient | （-0.036±10%）×10-6/°2 | Annual aging rate | ±3×10-6 |
